Permalloy core |
|
| Product name：Permalloy core |
| Item：16 |
| Details： |
| Application |
Features |
※ Zero-phase Current
※ Current transformer |
※ Especially high initial permeability
※ Hing saturation flux density
※ Low iron loss
※ Perfect resistance to the heavy current shock
※ Excellent temperature stability
※ Rohs |
|
Specifications
|
|
Part No
|
Core/case dimensions(mm)
|
Test condition
|
|
OD
|
ID
|
HT
|
Primary/Secondary Truns N1:N2
|
Input current(mA)
|
Output Voltage(mV)
|
|
HP1205N
|
12.00
|
8.00
|
5.00
|
1:1
|
50
|
1.00
|
|
13.60
|
6.40
|
7.10
|
|
HP1303N
|
13.50
|
10.00
|
3.20
|
1:1
|
25
|
0.20
|
|
15.00
|
8.70
|
4.50
|
|
HP1806N
|
18.50
|
11.50
|
6.50
|
1:1
|
50
|
2.00
|
|
20.20
|
10.20
|
8.00
|
|
HP1906N
|
19.00
|
14.00
|
6.50
|
1:1
|
50
|
1.80
|
|
22.20
|
12.00
|
9.20
|
|
HP1908N
|
19.00
|
14.00
|
8.00
|
1:1
|
50
|
2.00
|
|
21.60
|
12.00
|
11.00
|
|
HP2104N
|
21.00
|
17.00
|
4.50
|
1:1
|
50
|
2.00
|
|
24.00
|
14.50
|
6.50
|
|
HP2504N
|
25.00
|
19.00
|
4.50
|
1:1
|
50
|
2.00
|
|
28.00
|
17.50
|
6.70
|
|
HP2610N
|
26.00
|
16.00
|
10.00
|
1:1
|
50
|
2.00
|
|
28.50
|
14.00
|
12.20
|
|
HP3804N
|
37.00
|
29.00
|
4.00
|
1:1
|
50
|
2.00
|
|
38.50
|
27.40
|
5.60
|
|
|
 |
